MX15EDGKNHG-3.50 Female double row pitch 3.50mm with flange Wholesale

Home / Products / Terminal series / Pluggable terminal block / PCB plug / MX15EDGKNHG-3.50 Female double row pitch 3.50mm with flange

MX15EDGKNHG-3.50 Female double row pitch 3.50mm with flange

Pitch:3.50mm
  • MX15EDGKNHG-3.50 Female double row pitch 3.50mm with flange
  • MX15EDGKNHG-3.50 Female double row pitch 3.50mm with flange
  • MX15EDGKNHG-3.50 Female double row pitch 3.50mm with flange
Product description Technical parameter Technical drawing Ordering method


Product brand:

Product color:
Green・Black・Other colors customized
Product bits:
2-24P can be produced
Product services:
Provide specification/step quotation/professional and attentive after-sales service
Product advantages:
Small spacing, space saving
Parallel feed, flange handle fixed, simple and convenient operation
Can connect wire cross-sectional area of 28~18AWG (0.2~1.5mm² )
Plug and socket protection against misplacing
Environmentally friendly flame retardant grade UL94V-0
Internal components of the terminal:
Plastic shell: Nylon PA66
Shrapnel: stainless steel, good ductility, high elasticity
Conductive parts: nickel-plated phosphor bronze, strong resistance to oxidation
